Features of Chemical Injection Dosing Pump
- Pump SS 316 or as liquid Parameters
- Pump Operation with Compressed Air or Natural Gas
- Ceramic Plunger - Plunger coated with ceramic
- Plunger Type
- Flow Control by stroking rate with Stroke Delay Timer and stroke length variation with an accurate Micro Meter Stroke Adjustment Device
- Pressure Amplification ration 1:20
- Intrinsically Safe Operation
- Max Pressure 150kg/cm2
- Steady State Accuracy +_ 1.0% or better
- Input Air/Gas Supply :2-9 kg/cm2
- Simple operation
- Minimum working parts
- Field serviceable pumps
- Field adjustable maximum pressure cut off by control of Input Air supply from Air Filter Regulator Assembly
- Supplied with inbuilt Filter Regulator Assembly and Flow calibration/flow Rate Pot.
Operating Cycle
Power Stroke: As the supply Air/Gas from the Air Timer thru the Pneumatic Drive Cylinder. The Piston - Plunger Assembly is driven down into the fluid Cylinder, Displacing Fluid. The fluid displacement result in an increase in pressure which closes the Suction Valve and opens Discharge Valve . A precise of fluid, corresponding to stroke of the plunger is discharged.
Suction Stroke: When the Air/Gas is exhausted from the top portion of Pneumatic Drive Cylinder through the Air Timer, Air/Gas is then supplied to the bottom portion of the Pneumatic Drive Cylinder in order to return the Piston-plunger to its original position. The piston -Plunger assembly allows the discharge Valve to close and the suction Valve to open. The fluid chamber is then refilled and ready for the power stroke.
Installation
- Scrubber unit installed on supply flow line
- Step down regulator with pressure gauge
- Supply line tubing
- Drop out tank with drain
- Suitable Tubing ball valve
- Suitable Tee at pump supply inlet with pressure gauge
- Chemical supply tank
- Ball valves
- Pump setting Guage
- In line discharge check valve
- In line suction filter
|
